Description
The DPM series consists of three units: DPM-MAIN, DPM-EVA, and DPM-KPD, compatible with the BOUTIQUE PA/VA system and UAP G3 audio processor. The DPM-MAIN is the core digital paging console with programmable buttons and a talk button, the DPM-KPD is a keypad that expands the number of programmable keys and the DPM-EVA is a monitoring speaker pad with an EVAC button and 5 additional programmable buttons. Up to 16 consoles can connect to the BTQ-SL8, and up to 32 to the BTQ-VM4/VM8/SG8 or UAP G3, using daisy-chain or redundant loop wiring. The DPM-MAIN supports up to 15 expansion units, either: 1 DPM-EVA + 14 DPM-KPD, or 15 DPM-KPD. Programmable buttons can be assigned to single/group zones, zone paging, event triggering, recording, message routing/playback, and more—easily configured via a web browser. The talk button supports PTT or latching mode.
