Description
The CD-8DF and CD-16DF are wall-mount paging consoles with 8 or 16 keys and EVAC buttons, compatible with BOUTIQUE systems. Housed in lockable, heavy-duty IP30-rated metal enclosures, they feature configurable keys for zone selection, event triggering, recording, message playback, and more—set via a web browser. The talk button supports both PTT and latching modes. Both models include a fireman microphone and evacuation button.
Up to 16 consoles can connect to the BTQ-SL8, and 32 to the BTQ-VM4/VM8/SG8, using daisy-chain or redundant loop wiring. Maximum cable length is 250 m (820 ft) via STP CAT5/6 with shielded RJ45 connectors.
These eco-friendly units consume less than 1.5 W in standby mode.
